Memory and Brain Waves

Remembering is important for everyday life. It helps us with lots of things, such as remembering to do homework or knowing the answers for a test. Most times forgetting is normal, but occasionally it can be caused by damage to the brain or certain diseases. Our experiments studied the long-term version of memory, which includes things like remembering your first day of school or a friend’s birthday party. These memories happen in the brain due to the activity patterns of brain cells in different brain areas, working together to remember. The brain cells, called neurons, send electrical signals back and forth in just the right sequences, like friends throwing a ball back and forth. The brain is made of millions of neurons, and their patterns of electrical activity are called brainwaves. Brain waves are like waves at the beach: they can be big or small, and fast or slow. The speed of the brain waves is called frequency, measured in a unit called hertz (Hz). Hertz tells us how many times the brain waves happen in 1 s. But to make it easier, brain waves are usually referred to by names. One of the slowest brainwaves is called theta and it occurs four to eight times per second (4–8 Hz). Theta happens while people are very relaxed or during sleep. A faster brainwave, called beta, occurs twelve to sixteen times per second (12–16 Hz). Beta is usually found when people are awake and conscious.

Can the Brain Be Trained to Have Certain Brain Waves?

The rhythmic patterns of brain activity can be changed through a process known as entrainment. That is, we can train the brain to work at different frequencies. This is like getting a musical band to play together at a faster or slower speed, or like tuning into a specific radio station. Entrainment works by giving the brain inputs, like sounds and lights, at the frequency we want it to be in. We can do this using goggles that flicker lights at the exact frequencies that we want the brain to be in, or we can use headphones to play sounds (beeps) at just the right frequency. These methods can entrain the brain without hurting it.

In our study, we wanted to see if entrainment could improve memory by boosting the theta waves. We got the idea to do this because our prior studies had shown that theta waves happen just before a person remembers something correctly [1]. This was surprising and exciting to scientists, because our finding meant it could be possible to improve a person’s memory by changing the brain activity happening right before remembering—imagine that! Could boosting theta waves actually improve what people remember? We predicted that boosting theta waves by audio-visual entrainment would result in improved memory.

How Did We Test Our Predictions?

Two experiments were done to see if boosting theta waves would improve memory. The first experiment compared a boost of theta waves to a boost of random patterns, called white noise. The second compared boosting theta waves to boosting beta waves. In both experiments, people first studied a list of 200 words, one at a time. Later they had a memory test in which those same words were mixed with 100 new words. As words appeared before them one at a time, the participants were asked to remember whether each word was had been studied in the first part of the experiment. In between the studying and the memory test, there was a 36-min period of audio-visual entrainment, using headphones, and googles as described above (Figure 1). The goggles blocked out everything except the flickering lights and the headphones blocked all sounds except those being presented. We could control the volume of the sounds and the brightness of lights. The type of audio-visual stimulation depended on the group people were assigned to—participants saw and heard either theta, beta, or random patterns.

In the first experiment, 50 people (26 females, 24 males, aged 18–25) were tested. They were divided equally into two groups. The experimental group received lights and sounds that boosted theta waves (5 Hz). The control group received a random pattern of flickering lights and sounds (white noise), and this group was used as a comparison. None of the participants knew which group they were placed in. In the second experiment, 40 new people were tested (22 females, 18 males, aged 18–26). Again, they were separated into two groups that received different entrainment patterns. This time, one group received theta entrainment (5 Hz) and the other group received beta entrainment (14 Hz). This was done to see if training other brain patterns would also improve memory, or if memory improvement was specific to theta.

But how can we visualize what is going on in the participants’ brains without getting inside their heads? Electroencephalography (EEG) is a safe way to measure the electrical activity produced by brain waves, without surgery. It simply involves placing a cap with sensors called electrodes on a person’s head “Measuring Brain Waves in the Classroom" [2]. Scientists can compare EEG results when people remember something successfully vs. when they forget. The difference in the EEG readout tells us what the brain activity for memory looks like. Our earlier studies found that theta waves in the front part of the brain predicted successful memory. So, in these experiments, we also looked for theta activity in the front of the brain during the time of the experiments when people were remembering.

Was Our Prediction Correct? (Spoiler Alert: Yes!)

Our first experiment showed that the group receiving theta entrainment had better memory than the group receiving random noise (Figure 2). This suggested that audio-visual stimulation in the theta range improved memory. But how do we know that it was theta entrainment that made the difference? That is where our second experiment came in. We wanted to see if memory improved when beta waves were boosted, or whether the effect was specific for the theta group. Results of this second experiment showed that only the group receiving the theta boosts showed improvements in memory: the group receiving beta stimulation showed no memory improvement (Figure 2).

Results of the EEG showed that people’s brainwaves were boosted in the same patterns that they were receiving from the entrainment devices (Figure 3). This means that people who received theta entrainment showed increased theta waves during the memory test, and beta entrainment likewise boosted beta waves (but importantly- did not improve memory). This was important because it meant that entrainment was actually working to change the brain.

So What?

We found that entrainment can safely manipulate brainwaves to improve memory. Every study has some strengths and weaknesses. One of the strengths of this study is that it used two experiments and good control groups for comparisons that ruled out alternative possibilities. While this is exciting, there is still much work to be done. For instance, one limitation is that we do not know the minimum amount of time needed for entrainment to work, since we only tested 36 min of entrainment. We also do not yet know how long the memory improvements last, and it is important to note that it has not been tested in kids yet and the flashing lights may not be safe for people who have epilepsy. We must also remember that although we showed that training of theta waves boosted later memory scores and also boosted theta activity in the brain during memory, this does not necessarily mean that the boosted theta activity during the memory portion of the experiment caused the improved memory—just that the entrainment improved both memory and later theta waves. However, other studies have shown that memory scores can be caused by different brain waves such as theta [1, 3–5].

There are many exciting potential applications of these findings in the future. One hope is that we can use entrainment devices to help people who suffer from memory disorders. For example, entrainment could possibly help older people who forget many things, people with head injuries, or those with diseases that affect memory [3–5]. Entrainment of brainwaves might also help people to improve memory performance in normal situations, too. It could help people improve in school, in sports, or in their jobs. For instance, entrainment could be used to help astronauts flying in space to avoid memory mistakes! We are currently doing research to explore these possibilities, so stay tuned—better learning and memory may be as simple as getting into the right state of mind. So, “Think Theta!”

Glossary

Neuron: ↑ Cells within the nervous system, including cells in the brain and the spinal cord, that send (and receive) electrical messages with other cells.

Frequency: ↑ In brain recording, how many times a signal (or wave) happens in a second.

Hertz: ↑ The basic unit of measure for frequency, or how many times a signal (or wave) happens in a second. It is abbreviated as (Hz).

Theta Brain Waves: ↑ Slow brainwaves, with a frequency of 4–6 Hz, which are common in sleep, relaxation, and deep meditation.

Beta Brain Waves: ↑ Fast brainwaves, with a frequency of 12–16 Hz, which are commonly associated with being awake and conscious.

Entrainment: ↑ Synchronization of brainwaves with external stimuli, which can include pulses of light and sound at specific frequencies. Entrainment guides the brain gently and safely into specific brain wave patterns.

White Noise: ↑ A random signal like the “snowy” view on a television screen with no signal or a scratchy radio station on which you hear only static sounds.

Electroencephalogram (EEG): ↑ A technique for measuring the electrical activity of the brain, using a cap with sensors called electrodes, which is worn over a person’s head.
